Ultra High Security 100V 512V High Voltage Stacked Energy Storage Battery 15Kwh 20Kwh 25Kwh

Place of Origin : china

MOQ : negotiated

Price : negotiated

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : negotiated

Battery Type : LiFePO4

Output Power Range : 10~20 kWh

Protection Class : IP54

Cycle life : 6000 Cycles

Warranty : 5 YEARS

Nominal Voltage : 204V

Contact Now

Ultra High Security 100V 512V High Voltage Stacked Energy Storage Battery 15Kwh 20Kwh 25Kwh

Product Description

Model No	204V50Ah	307V50Ah	409V50Ah	512V50Ah
Voltage	204V	307V	409V	512V
Capacity	50Ah
Energy	10.2KWh	15.35KWh	20.5KWh	25.6KWh
Dimensions(LWH)	590360600mm	590360750mm	590360900mm	5903601050mm
Weight(kg)	95kg(about)	133kg(about)	172kg(about)	212kg(about)
Operation temperature	-10℃~60℃@60±20%RelativeHumidity
Storage temperature	0℃~45℃@60±20%RelativeHumidity
Protection grade	IP21
Operation voltage	204V	307V	409V	512V
Max.chargingvoltage	233V	350V	467V	467V
Cut-off discharge voltage	160V	240V	320V	400V
Max.Chargingcurrent	25A
Max.Discharging current	50A

Inverter Type	Single Phase	3 Phase	Split Phase
Output Power	3-16KW	5-30KW	5-8KW
Output Voltage	220/230/240V	220/380V, 230/400	120/240V

Ultra High Security 100V 512V High Voltage Stacked Energy Storage Battery 15Kwh 20Kwh 25Kwh

Touch Display and High Voltage Box

Single module with 5 kilowatt hours of electricityfreely stacked

Load bearing casters for easy movement

Company Introduction

About Us

Guangzhou New Energy Co., Ltd. is a high-tech green energy enterprise integrating independent research, development, production and sales of lithium-ion battery modules. The company operates in strict accordance with iso9001-2015 quality management system and has passed ISO14000 system certification. The manufacturing workshop is equipped with advanced production equipment and first-class testing instruments. At the same time, it has a group of professional production and quality management teams, which strictly control every step of the production process and ensure to provide customers with first-class quality products through continuous optimization and improvement of technology. It has a number of lithium battery pack production lines, aging, capacity sharing and other production equipment and a large number of experienced industrial workers.

FAQ

Q1.Which certificates do you have?
A:We have CE/FCC/ROHS/UN38.3/MSDS ...etc.

Q2.How about warranty?
A:5 year warranty

Q3: Are these battery packs compatible with my inverter?
A: Yes, Sir/Madam.Our battery pack is compatible with most brands of inverters on the market.
Contact us and let me tell you more.

Q4. How do you ship the goods and how long does it take to arrive?
A.It usually takes 5-7 days to arrive. Train and Airline and Sea(DDP) shipping is also optional.

Q5: How do I know whether you've shipped my order or not?
A: Tracking No. will be offered as soon as your order be shipped out. Before that, our sales will be there to check the packing
status, photo you the done order and let you know the forwarder picked it up.
